CWDM SFP

Description:

The CWDM SFP small form-factor pluggable (SFP) is a compact optical transceiver used in optical communications for both telecommunication and data communications applications on the CWDM SFP 1270, CWDM SFP 1290, CWDM SFP 1310, CWDM SFP 1330, CWDM SFP 1350, CWDM SFP 1370, CWDM SFP 1390, CWDM SFP 1410, CWDM SFP 1430, CWDM SFP 1450, CWDM SFP 1470, CWDM SFP 1490, CWDM SFP 1510, CWDM SFP 1530, CWDM SFP 1550, CWDM SFP 1570, CWDM SFP 1590, CWDM SFP 1610. Wavelength. It is a popular industry format supported by several fiber optic component vendors. SFP transceivers are designed to support SONET/SDH, Gigabit Ethernet, Fiber Channel, and other communications standards SFP transceivers are available with a variety of different transmitter and receiver types, allowing users to select the appropriate transceiver for each link to provide the required optical reach over the available optical fiber. 10GTEK offers CWDM SFP transceivers which reach distances from 40KM up to 120KM. frequently used wavelength: 1470nm, 1490nm, 1510nm, 1530nm, 1550nm, 1570nm, 1590nm, 1610nm. Other wavelength options: 1270nm, 1290nm, 1310nm, 1330nm, 1350nm, 1370nm, 1390nm, 1410nm, 1430nm, 1450nm

Features:

1.1Hot-pluggable SFP Footprint

2. Dual LC Connectors

3. Wide distance Supported from 500m to 120km

4. Built-in Digital Diagnostic Functions Optional

5. Metal Enclosure for Lower EMI

6. Comply with SFP MSA

7. Comply with SDH/SONET

8. Comply with IEEE Std 802.3

9.18-Wavelength CWDM 1270 nm to 1610 nm Available

10. DWDM 100GHz ITU Grid C Band Available

11. Single +3.3V Power Supply

12. Operation Temperature Range 0~70℃

13. Low Power Dissipation

14. RoHS-6 Compliant
